The PE4716 BNC male, reverse polarity connector features a crimp/solder attachment method for attaching to RG303, RG141, PE-C195, PE-P195, LMR-195, 0.195 inch coax cables. This connector offers a maximum VSWR of 1.3:1 up to 4 GHz and has a straight body geometry.
- Straight body geometry
- VSWR of 1.3:1 up to 4 GHz
- Gold-plated brass contact
- Reverse polarity
- RG303, RG141, PE-C195, PE-P195, LMR-195, 0.195 inch interface types
AI disclosure: this description was generated with AI assistance from this product's own listing data.
Product Codes | |
|---|---|
| Mfr Part No: | PE4716 |
| ECCN: | EAR99 |
| SCHEDULE B CODE: | 8536.69.4010 |
Weight: 0.027 lb (12.25 g)Dimensions: 1.09 x 0.57 in (27.69 x 14.48 mm)Frequency Range: DC – 4 GHzVSWR: 1.3:1Connector Type: BNC male (reverse polarity)Impedance: 50ΩOperating Voltage: 500 Vrms ACContact Material: Gold-plated brass (30 µ-in min.)Insulation Material: PTFEBody Material nickel-plate brass (100 µ-in min.)Coupling Nut Material: nickel-plated brass (100 µ-in min.)Operating Temperature: -65°C to 165°CCable Compatibility: RG303, RG141, PE-C195, PE-P195, LMR-195, 0.195 inch interface types
- Stock: Out of Stock
- Manufacturer Part #: PE4716
