Overview
The Lycoming Oil Drain Tube Assembly (P/N LW-15361) serves a critical function within the lubrication system of specified Lycoming piston engines, specifically directing spent oil from cylinder number one. This component is integral to the engine's ability to efficiently manage and drain engine oil, preventing accumulation and ensuring proper flow during maintenance operations. Positioned to facilitate the complete removal of oil from the cylinder area, the LW-15361 tube assembly helps maintain engine cleanliness and supports effective oil changes, which are fundamental to engine longevity and performance. Its design ensures a secure and leak-free pathway for the oil.Specifications
- Part Number: LW-15361
- Component Type: Oil Drain Tube Assembly
- Application Point: Cylinder No. 1
- Material: Constructed from a corrosion-resistant metal alloy, specifically chosen for its durability and resistance to engine oil, heat, and vibration found within the engine compartment.
- Fittings: Features precisely machined ends designed to integrate seamlessly with the engine's existing oil system connections, ensuring a tight seal.
- Form Factor: A pre-formed tube, engineered with specific bends and lengths to fit the exact configuration of the Lycoming O-320-H engine, ensuring correct routing and clearance.
- Finish: Typically exhibits a natural metal finish, unpainted, to allow for visual inspection of the material integrity.
Aircraft Compatibility
This Lycoming Oil Drain Tube Assembly, part number LW-15361, is specifically engineered for precise fitment and function within the Lycoming O-320-H (76 Series) engine. This particular engine variant is a four-cylinder, direct-drive, air-cooled, horizontally opposed aircraft engine renowned fo1 required per aircraft (per the manufacturer IPC).
- Stock: Out of Stock - On Backorder
- Manufacturer Part #: LW-15361
- Part#: LW-15361
