The nose landing gear drag link bracket, precisely identified by Piper Part Number 63900-07, is a vital structural component designed to secure the nose gear drag link within the airframe. This bracket plays a foundational role in the stability and operational integrity of the aircraft's steerable nose landing gear system, managing forces exerted during taxiing, takeoff, and landing operations. Its robust construction ensures proper alignment and function of the nose wheel assembly, transmitting steering inputs and absorbing various ground loads.
Aircraft Fitment
This specific drag link bracket, Part Number 63900-07, is engineered for direct compatibility with the following Piper aircraft models and serial number ranges:
- Piper PA-28-161 Cadet: Applicable to all serial numbers.
- Piper PA-28-161 Warrior II: Applicable to all serial numbers.
Owners, A&P mechanics, and FBO maintenance shops should always consult the relevant Illustrated Parts Catalog (IPC) and maintenance manuals for their specific aircraft serial number to confirm exact applicability of the 63900-07 bracket.
Overview
The nose landing gear drag link bracket (P/N 63900-07) is an essential element within the Piper PA-28-161 nose gear assembly. It serves as a fixed anchor point, connecting the movable nose gear strut to the aircraft's main structural framework via the drag link. This connection is fundamental for transferring steering commands from the rudder pedals to the nose wheel and for maintaining the fore-aft stability of the nose gear during ground operations. Its design is optimized to withstand the dynamic stresses associated with typical flight training and general aviation usage, ensuring reliable performance of the landing gear system.
- Stock: Out of Stock - On Backorder
- Manufacturer Part #: 63900-07
- Part#: 63900-07
