The Piper PA-28 Flap Hinge Bracket Assembly, identified by part number 65356-00, is a critical structural component within the wing flap system of various Cherokee series aircraft. This precisely engineered bracket serves to securely attach the flap panel to the main wing structure, facilitating the rotational movement essential for flap deployment and retraction. It bears significant aerodynamic loads during flight, particularly during takeoff and landing phases, directly influencing the aircraft's lift and drag characteristics. The integrity of each 65356-00 bracket is paramount for the safe and reliable operation of the flap system.
Specifications
- Part Number: 65356-00
- Material: High-strength aluminum alloy (e.g., 2024-T3 or 7075-T6 equivalent, per original Piper specifications for structural components)
- Finish: Chemically conversion coated (chromate) and/or anodized for corrosion resistance
- Approximate Weight: 0.25 - 0.45 lbs (individual bracket, estimates based on typical light aircraft structural components)
- Dimensions: Approximately 4.0 inches (length) x 1.5 inches (width) x 1.0 inch (height) – specific dimensions vary slightly based on exact flap station and wing contour. Features precise drilling and reaming for pivot pin and attachment hardware.
- Design: Machined or formed bracket with integrated mounting holes and a pivot point for the flap hinge pin.
Aircraft Compatibility
The 65356-00 Flap Hinge Bracket Assembly is designed for a wide range of Piper PA-28 Cherokee models,
- Stock: Out of Stock
- Manufacturer Part #: 65356-00
- Part#: 65356-00
