TELEPHONE PLUG/U384/U, military, mil spec m642/14-01, 5 conductor, overall diameter of plug housing .625 inch, overall length: 2.1875 inch, contact diameter: .281 inch , plug contact length: .901 inch. TP-105

TELEPHONE PLUG/U384/U, military, mil spec m642/14-01, 5 conductor, overall diameter of plug housing .625 inch, overall length: 2.1875 inch, contact diameter: .281 inch , plug contact length: .901 inch.  TP-105
Out of Stock - On Backorder
TELEPHONE PLUG/U384/U, military, mil spec m642/14-01, 5 conductor, overall diameter of plug housing .625 inch, overall length: 2.1875 inch, contact diameter: .281 inch , plug contact length: .901 inch. TP-105
TELEPHONE PLUG/U384/U, military, mil spec m642/14-01, 5 conductor, overall diameter of plug housing .625 inch, overall length: 2.1875 inch, contact diameter: .281 inch , plug contact length: .901 inch. TP-105
TP-105 5-Conductor Telephone Plug

The TP-105 telephone plug is a five-conductor plug molded into a red plastic body. Mates with Nexus series TJ-105 and TJT-125 jacks.


  • 5-Conductor telephone plug
  • One piece monel contacts
  • Mates with Nexus series TJ-105 and TJT-125 jack
  • Includes: TP-105-12 case, TJ-105-13 strain relief clamp, TP-105-7 stack assembly

Product Codes

Mfr Part No:TP-105
MIL SPEC:M642/14-01
ECCN:EAR99
MIL SPEC:M642/14-01
SCHEDULE B CODE:8536.69.4020


Diameter: 0.625 x 2.188 x 0.281 inNumber of Conductors: 5Shell Material: plasticContact Material: MonelSolder Contact Terminals: pre-tinned over nickelContact Resistance: ≤ 0.02 ΩInsulation Resistance: ≥ 1,000 MΩDielectric Withstanding Voltage: ≥ 500 V RMSInsertion Force: 13 lbWithdrawal Force: 6 to 10 lb
