Overview
The Beechcraft structural bolt, designated P/N 012-028, serves as a critical fastening component within the airframe assemblies of the T-34 Mentor. This specific hardware item is designed to secure various structural and non-structural elements, ensuring the mechanical integrity and safe operation of the aircraft. As a standard AN-series equivalent, this bolt provides robust connection points, resisting shear and tensile forces encountered during flight operations and ground handling.This particular bolt is typically found in applications where a 3/16-inch diameter fastener with a 3/8-inch grip length is required, often paired with appropriate washers and nuts to complete a secure joint. Its role is fundamental in maintaining the structural cohesion of the aircraft, from control surface attachments to internal airframe bracing. Proper selection and installation of P/N 012-028 are paramount for upholding the T-34 Mentor's airworthiness.Specifications
The Beechcraft P/N 012-028 bolt, equivalent to an AN3-6A specification, exhibits the following characteristics:- Type: Close Tolerance Bolt, Hex Head
- Material: Alloy Steel, typically 4130 or 8740, heat-treated
- Finish: Cadmium plated for corrosion resistance, conforming to QQ-P-416, Type II, Class 2
- Diameter: 0.1875 inches (3/16 inch)
- Grip Length: 0.375 inches (3/8 inch) – the unthreaded portion designed to pass through the material being joined
- Thread Length: Approximately 0.5625 inches (9/16 inch)
- Overall Length (L): Approximately 1.000 inch
- Head Style: Hexagonal, conforming to AN standards for aircraft bolts
- Head Height: Approximately 0.125 inches
- Head Width (Across Flats): Approximately 0.3125
- Stock: Out of Stock - On Backorder
- Manufacturer Part #: 012-028
- Part#: 012-028
