The PE9206 N female to BNC male adapter features a straight body geometry and a gold over nickel-plated brass contact. This connector also has maximum 1.5:1 VSWR up to 3 GHz with a 50Ω impedance and is MIL-STC-348A compliant.
- Straight body geometry
- 1.5:1 maximum VSWR up to3 GHz
- 50Ω impedance
- Gold over nickel-plated brass contacts
- N Female to BNC Female
AI disclosure: this description was generated with AI assistance from this product's own listing data.
Product Codes | |
|---|---|
| Mfr Part No: | PE9206 |
Width: 0.05 lb (22.68 mm)Dimensions: 1.102 x 0.625 in (27.99 x 18.55 mm)Frequency Range: DC – 3 GHzVSWR: 1.5:1Operating Voltage: 500 Vrms ACInner Conductor DC Resistance: 1.5 mΩOuter Conductor DC Resistance: 1 mΩb5,000 mΩConnector Type: N female (connector 1) BNC female (connector 2)Polarity: standardInterface Specifications: MIL-STD-348AMating Cycles: 500Contact Material: gold over nickel-plated brass (30 µ-in min.)Insulation: PTFEOuter Conductor: nickel-plated brass (100 µ-in min.)Operating Temperature: -65°C to 165°C
- Stock: Out of Stock
- Manufacturer Part #: PE9206
